FLIR T620 (15) Thermal Imaging Infrared Camera
Highest Thermal Imaging Resolution in Its Class
With 307,200 pixels at 640 × 480, FLIR T620 Thermal Imaging Camera give professional thermographers the highest thermal resolution and sensitivity for the best-looking images and most accurate temperature measurements. Coupled with dual 5 megapixel digital cameras, you’ll get the sharpest visible light and thermal images you need to create the most effective documentation. See the results jump off the screen.
Comfortable, Flexible Ergonomics: What T-Series is Famous For
Capturing great thermal images high above your head or down near the ground no longer needs to be a back-breaking, knee-cracking calisthenics routine. With a unique rotating optical block with its interchangeable lenses, the Flir T620 Thermal Imaging Camera lets you easily tilt up or down along its 120° range of motion while keeping the touchscreen display right in front of you. See how comfortable and easy it is to “get the shot” from any angle.
Industry-First Wi-Fi Connectivity Adds Power to Analysis, Reporting, and Sharing.
The Flir T620 simplifies your work life out in the field and in the office by leading the way with forward-thinking Wi-Fi to mobile devices like iPad, iPhone, and iPod Touch. No bulky laptops to lug, cables to connect, or SD cards to swap. Use the new FLIRViewer app to import images from the camera, add more box areas and moveable spots and fine-tune images. Generate comprehensive reports. And share critical information immediately with decision makers on-site or by e-mail. See how FLIR Wi-Fi connectivity can help boost your productivity and credibility.
High Resolution IR Images 307,200 pixels (640 x 480) Infrared resolution
Visible Light Digital Camera 5MP resolution with LED lamp provides sharp images regardless of lighting conditions
4X Continuous Zoom with auto/manual focus
Rotating lens detents up to 120° for easy viewing angle
Scalable Thermal Fusion blending of thermal and digital images
Scalable Picture in Picture (PIP) displays thermal image super-imposed over a digital image
Video Lamp allows the visual camera and fusion to be used in poorly lit environments
High Temperature Range measuring up to 3632°F (2000°C) targeting electrical and industrial applications
Thumbnail Image Gallery
Laser LocatIR Pointer
Voice Comment Recording on images
Bluetooth Wireless Communication
Instant Report creates a Thermographic Inspection report directly in the camera
Optional 15° Telephoto, 45° Wide Angle
Temperature Range -4°F to 3632°F (-20°C to 2000°C)
Image Storage 1000 radiometric JPEG images (SD card memory)
Imaging Performance / Image Presentation
Frame Rate 30Hz
Field of view/min focus distance 25° x 19°/9.8” (0.25m)
Thermal sensitivity (N.E.T.D) < 0.04ºC
Detector Type – Focal plane array
FPA) uncooled microbolometer 640 x 480 pixels
Spectral range 7.8 to 14μm
Display Built-in touch-screen 4.3″ color LCD
Image modes Thermal/Visual/Picture in Picture/Fusion
Image annotation Voice (60 sec); text comments, Sketch
Lens 25° (optional 15° Telephoto, 45° Wide Angle lenses available
Video Lamp Bright LED lamp
Laser Classification/Type Class 2/Semiconductor AlGalnP Diode Laser: 1mW/635nm (red)
Set-up Controls Mode selector, color palettes, configure info to be shown in image, local adaptation of units, language, date and time formats, and image gallery
Measurement Modes 10 Spotmeters, 5 Box areas, Isotherm, Auto hot/cold spot, Delta T
Measurement Correction Reflected ambient temperature and emissivity correction
Battery Type/operating time Li-lon/ >3 hours, Display shows battery status
Charging System In camera AC adapter/2 bay charging system
Shock 25G, IEC 68-2-29
Vibration 2G, IEC 68-2-6
Dimensions/Weight 5.6×7.7×3.7″ (143x195x95mm)/2.87lbs (1.3kg), including battery
