FLUKE RSE300 MOUNTED INFRARED CAMERA

  • MATLAB® and LabVIEW® software compatibility allows users to integrate infrared data, images and videos to support R&D analysis
  • 320 x 240 resolution
  • See the details you need with optional smart lenses: 2x and 4x telephoto, wide angle and macro lenses
  • Optimize images, generate customizable reports and export images to the format of your choice with SmartView® desktop software
  • Wirelessly connect your camera to the Fluke Connect® system to easily share and edit images
Key Features
IFOV with standard lens (spatial resolution) 1.31 mRad
Detector resolution 320 x 240 (76,800 pixels)
Field of view 24 °H x 18 °V
Minimum focus distance 15 cm (approx. 6 in)
Camera focus options Focus is adjusted in SmartView® desktop software
Wireless connectivity Yes, to PC, iPhone® and iPad® (iOS 4s and later), Android™ 4.3 and up, and WiFi to LAN (where available)
IR-Fusion®technology Yes, in SmartView® desktop software. Five modes of image blending (AutoBlend™ mode, Picture-in-Picture (PIP), IR/Visible alarm, Full IR, Full visible light) add the context of the visible details to your infrared image
Thermal sensitivity (NETD) ≤ 0.040 °C at 30 °C target temp (40 mK)*
Filter mode (NETD improvement) Yes
Level and span Smooth auto and manual scaling, in SmartView® desktop software
Fast auto toggle between manual and auto modes Yes, in SmartView® desktop software
Fast auto-rescale in manual mode Yes, in SmartView® desktop software
Minimum span (in manual mode) 0.1 °C (0.18 °F), in SmartView® desktop software
Minimum span (in auto mode) <1.0 °C (<1.8 °F), in SmartView® desktop software
Built-in digital camera (visible light) 5 megapixel industrial performance
Frame rate 60 Hz or 9 Hz versions
Digital zoom Variable up to 16x in SmartView® desktop software
*Best possible



Data storage and image capture
Memory options Connect to SmartView® desktop software for storage to device or upload to Fluke Cloud™ for permanent storage Capture, save and analyze images in SmartView®desktop software
Image capture, review, save mechanism Image file formats Non-radiometric (.bmp) or (.jpeg) or fully-radiometric (.is2); no analysis software required for non-radiometric (.bmp, .jpg and .avi) files
Software SmartView® desktop software—full analysis and reporting software Compatible with MATLAB® and LabVIEW® software
Export file formats with SmartView®desktop software Bitmap (.bmp), GIF, JPEG, PNG, TIFF
Voice annotation Yes, in SmartView® desktop software
Text annotation Yes, in SmartView® desktop software
Video recording Yes, in SmartView® desktop software
File formats video Non-radiometric (MPEG-encoded .AVI) and fully-radiometric (.IS3), in SmartView®software
Remote display viewing Yes, see the live stream of the camera display on your PC, smartphone, or TV monitor. Via USB, WiFi hotspot, or WiFi network to SmartView® desktop software on a PC; via WiFi hotspot to the Fluke Connect® app
Remote control operation Yes, through ethernet or SmartView® desktop software



Temperature measurement
Temperature measurement range (not calibrated below -10 °C) -10 °C to +1200 °C (14 °F to +2192 °F)
Accuracy ± 2 °C or ± 2 %, whichever is greater
Reflected background temperature compensation Yes, in SmartView® desktop software
Transmission correction Yes, in SmartView® desktop software
Live line marker Yes, in SmartView® desktop software



Color Palettes
Standard palettes 8: Ironbow, Blue-Red, High Contrast, Amber, Amber Inverted, Hot Metal, Grayscale, Grayscale Inverted
Ultra Contrast™ palettes 8: Ironbow Ultra, Blue-Red Ultra, High Contrast Ultra, Amber Ultra, Amber Inverted Ultra, Hot Metal Ultra, Grayscale Ultra, Grayscale Inverted Ultra



General specifications
Color alarms (temperature alarms) Yes, in SmartView® desktop software–high temperature, low temperature, and isotherms (within range)
Infrared spectral band 8 μm to 14 μm (long wave)
Operating temperature -10 °C to +50 °C (14 °F to 122 °F)
Storage temperature -20 °C to +50 °C (-4 °F to 122 °F) without batteries
Relative humidity 10 % to 95 % non-condensing
Center-Point temperature measurement Yes, in SmartView® desktop software
Spot temperature Yes, in SmartView® desktop software–hot and cold spot markers
User-definable spot moarkers 3 user-definable spot markers, in desktop software
Center box Expandable-contractible measurement box with MIN-MAX-AVG temp display, in desktop software
Electromagnetic compatibility EN 61326-1:2013 IEC 61326-1:2013; (Industrial)
US FCC CFR 47, Part 15 Subpart B Class A
Vibration IEC 60068-2-26 (sinusoidal vibration): 3G, 11–200 Hz, 3 axis
Shock IEC 60068-2-27 (mechanical shock): 50G, 6 ms, 3 axis
Size (H x W x L) 8.3 cm x 8.3 cm x 16.5 cm (3.3 in x 3.3 in x 6.5 in)
Weight (battery not included) 1 kg (2.2 lb)
Enclosure rating IEC 60529: IP67 (protected against dust, limited ingress; protection against water spray from all directions)
Recommended calibration cycle Two-years (assumes normal operation and normal aging)
Supported languages Czech, Dutch, English, Finnish, French, German, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, and Turkish
SmartView® desktop analysis and reporting software is available in all countries but Fluke Connect®wireless system is not. Please check availability with your authorized Fluke distributor.



Thermal Imaging adalah salah satu metode pendeteksian yang meningkatkan visibilitas objek dalam gelap dengan mendeteksi radiasi inframerah dari benda dan menciptakan gambar berdasarkan informasi tersebut.Thermal Imaging, Infrared dan Low-Light Imaging adalah tiga teknologi yang paling sering dipakai dalam penggunaan night vision. Berbeda dengan dua metode lainnya, thermal imaging bekerja di lingkungan tanpa cahaya. Seperti near-infrared illumination, thermal imaging dapat menembus benda-benda gas seperti asap dan kabut. Cara kerja thermal imaging adalah semua benda memancarkan energi inframerah (panas) sebagai fungsi temperature. Energi inframerah yang dipancarkan oleh sebuah objek yang dikenal sebagai heat-imaging.
Update Jual FLUKE RSE300 MOUNTED INFRARED CAMERA dengan harga murah dan garansi resmi dari distributor. Dapatkan produk terbaik dari merek Fluke dengan spesifikasi lengkap.

Belanja online Thermal Imaging hanya di Kucari dengan kualitas terbaik, harga murah bersaing, bisa COD, Gratis pengiriman wilayah Jakarta dan sekitarnya. Beli sekarang hanya di toko online terpercaya.

Pengiriman ke seluruh Indonesia seperti Jakarta, Bandung, Bekasi, Depok, Cikarang, Tangerang, Lampung, Pontianak, Jogja, Semarang, Solo, Batam, Padang, Pekanbaru, Malang, Surabaya, Medan, Makassar, Balikpapan, Samarinda, Palembang, Riau, Aceh, Manado, NTT, NTB, Papua dan Bali Denpasar.

Specification: FLUKE RSE300 MOUNTED INFRARED CAMERA

Berat 1 kg
