BK Precision 2652A Spectrum Analyzer

BK Precision 2652A is a compact, light weight and cost-effective spectrum analyzer for quick and precise signal investigations, especially away from the bench. The 2652A is a 2650A with a tracking generator added and can be used to rapidly determine transmission characteristics of two-port RF devices.

At a weight of only 4 pounds (1.8 kg), the 2652A is by far the lightest full-featured spectrum analyzer available, yet it delivers performance and features comparable to a full-size bench spectrum analyzer and can operate up to 4 hours on a single battery. With its ease of use, measurement flexibility and unmatched portability, the 2652A spectrum analyzer is an indispensible tool for engineers and technicians who conduct field measurements in the 50 kHz to 3.3 GHz range.

Features :

Frequency response measurements of passive components such as RF cables, filters, and attenuators
Installation, maintenance, and trouble shooting of wireless communication systems such as W-CDMA/CDMA, GSM, WLAN and Bluetooth
Detection of signal interference and undesired emissions
TV and broadcasting
Antenna alignment
Electric field strength measurement with dipole antennas (order M401-M406)
Magnetic field strength measurement with magnetic field probe (order PR 26M)
EMI compliance (E & H field measurements with optional accessories)
Large easy-to-read color display, 640 x 480 resolution
Convenient USB host port: save screen images and measurement results directly to a USB drive
DANL (displayed average noise level) of -127 dBm
Measurement functions: channel/adjacent channel power, occupied bandwidth, electric and magnetic field strength
Easy operation due to Auto Tuning
Fast sweep speed, minimum 10 ms, to help locate and identify elusive, transient interference signals

Includes :

AC Adaptor (BC 2650)
Soft Carrying Case
Accessory Pouch
Fuse
BP 2650 Ni-MH Battery Pack
Operation Manual
