GW Instek LCR6200 High Precision LCR Meter

GW Instek LCR6200 High Precision LCR Meter has a test frequency range of 200kHz and 0.05% basic accuracy. The compact size design, 2U height and 1/2 rack, is one of the practical features of the LCR-6200 which is the optimum space saver suitable for either bench top or system rack. The compact LCR-6200 with abundant features is absolutely the excellent tool for R&D, production test, IQC, etc. on implementing each test stages for passive components.

LCR6200 provides rich functionalities with the compact size. First of all, it adopts 3.5-inch color LCD and features opulent display parameters. In addition to simultaneously displaying setting criteria and measurement results, the LCR6200 increases two additional monitoring parameters. In other words, there are four parameters, primary/secondary and two monitoring, simultaneously shown on the screen that tremendously enhances the measurement efficiency. The enlarge display mode not only emphasizes the measurement results, but also provides PASS/FAIL judgment to facilitate a rapid and convenient test result.

Convenience is one of the unique features. The LCR-6200 comes equipped with two zero methods, which are full frequency range and spot. Users, without turning off the power and changing test fixture, can freely change frequency within the provided frequency range to conduct measurements. By so doing, tremendous time can be saved from repeatedly executing zero operation. Additionally, frequency range of the LCR6200 is consecutive that allows users to input precise frequency value to conduct the most genuine test on components.

LCR-6200 also features diverse ancillary measurements to meet the measurement requirements of different materials. For instance, the LCR-6200 provides the automatic level control (ALC) function to satisfy the test voltage requirement of MLCC. For inductive component measurements, the LCR-6200 provides the adjustable test current function and the D.C. resistance measurement function. The optional external bias current adapter (±2.5A) is to satisfy the measurement requirements. With respect to the D.C. bias voltage test for capacitive components requirements, the LCR-6200 allows users to conduct verification measurement on materials by its internal ±2.5V adjustable voltage or via an optional external bias voltage adapter (±45V). Furthermore, 10 steps of listed test functionalities allow users to set testing parameters (either by frequency, or voltage, or current) for each step based on users’ requirements in order to observe the trend of DUT characteristics.

LCR6200 has 10 memory sets defined by panel setting criteria to facilitate users in selecting test criteria and saving time in repeated settings. 10,000 measurement result storage capability can easily record measurement results instantaneously. The USB host allows easy access to recorded results without connecting the series to the PC. The USB host also allows USB to retrieve and save screen so as to assist users in compiling setting guidelines.

For the external control, the meter provides a handler interface and collocates with its measurement sorting function (9BIN, AUX: 1BIN) to facilitate the connection with sorting machine so as to sort out the materials. For remote control and measurement result retrieval requirements, the LCR-6200 series provides RS-232C to assist setting control or measurement result retrieval via the PC commands. Additionally, the free PC software gives users an instant tool to store measurement results that saves time in developing programs.

compacted LCR-6200 can effectively improve the limitation of space. Diverse measurement functionalities and display methods are making the series the high CP ratio choice in meeting the requirements of R&D, component assessment for engineering departments, category sorting requirements for component production, and IQC for verification on component specifications.

Features :

10 Hz ~ 200 kHz(±0.01%)
3.5″ color LCD
Consecutive test frequency
Basic accuracy : 0.05%
Measuring speed up to 25ms (max.)
Full frequency range or spot OPEN/SHORT
16 major/secondary parameter measurement combinations and two additional monitoring parameters(maximum four different parameters can be shown simultaneously)
DCR measurement and internal D.C. bias voltage (±2.5V)
PASS/FAIL judgment
Auto Level Control (ALC) function
BIN function provides 9BIN and 1AUX, totally 10 BIN
10 steps listed tests to select different frequency, voltage and current criteria
Standard interface : RS-232C, Handler and USB storage
Compact size, ideal for automatic equipment (2U,1/2 RACK)

What’s in the Box :

(1) Saftey Sheet
(1) Power Cord
(1) Test Fixture LCR-06A
